GODO A170 Automatic Drone Dock System | Drone-in-a-Box

SHENZHEN GODO INNOVATION TECHNOLOGY CO., LTD.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap GODO A170 Automatic Drone Dock System | Drone-in-a-Box from wholesalers

    Buy cheap GODO A170 Automatic Drone Dock System | Drone-in-a-Box from wholesalers
    • Buy cheap GODO A170 Automatic Drone Dock System | Drone-in-a-Box from wholesalers
    • Buy cheap GODO A170 Automatic Drone Dock System | Drone-in-a-Box from wholesalers

    GODO A170 Automatic Drone Dock System | Drone-in-a-Box

    Ask Lasest Price
    Brand Name : GODO UAV
    Model Number : GODO A170 Automatic Drone Dock System
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 6 days/set
    Delivery Time : 30+10 days/set (Excluding transportation time)
    • Product Details
    • Company Profile

    GODO A170 Automatic Drone Dock System | Drone-in-a-Box

    GODO A170 Automatic Drone Dock System

    Key features

    Auto Takeoff, Landing & Charging

    Versatile Accessories, Diverse Scenarios

    Automatic Battery Swap

    Real-time Weather Monitoring

    Multi-terminal Synchronization

    Advanced Digital Twin Technology

    Redudant Power Supply | Active Temperature Control | Cloud Management

    15s Automatic Battery Swap

    4 Sets of Battery

    7 * 24 Unattended Operation

    IP54 Protection IP54

    Rich Accessories Selection

    GODO A170 Automatic Drone Dock System | Drone-in-a-Box

    Configuration:

    A full function UAV dock

    One pcs of M190 drone

    2 user licenses for GODO Cloud Platform (or we provide the platform software for free to local installation)

    GODO A170 Automatic Drone Dock System | Drone-in-a-Box

    GODO A170 Automatic Drone Dock System | Drone-in-a-Box

    GODO A170 Automatic Drone Dock System | Drone-in-a-Box

    GODO A170 Automatic Drone Dock System | Drone-in-a-Box

    Specifications:

    Dimension 1860x1860x1920
    Weight 1000KG
    Ingress Protection IP54
    Peak Operation Power 3000W
    Power Supply AC200V~240V
    No. of Drone 1
    Battery Swap Automatic or Manual
    Automatic Battery Swap Time 15s
    Min Operation Interval 3 mins
    Sets of Battery 4
    Positioning Method RTK+Visual
    Night Landing Support
    Safety Protection Undervoltage, Overload, Power Protection
    Telecommunication 4G,5G
    Operating Temperature -20℃~60℃
    Built-in Thermostatic System Yes

    M190 Drone Specification

    Dimension 712*712*452mm
    Wheelbase 900mm
    Max Payload 5kg
    Max Take-off Weight 13.2kg
    Max Flight Time

    Without payload 70min

    3.5kg payload ≥35min

    Max Flight Altitude 5000 m
    Max Withstand Windspeed 15 m/s
    Operating Temperature -20°C ~ 50°C
    GNSS GPS+GLONASS+BeiDou+Galileo

    Designed for Remote Operation


    GODO A170 Automatic Drone Dock System | Drone-in-a-Box

    Applications:

    Patrol in difficult terrain

    Product advantages:


    Quick Response

    AI Identification

    Digital Twin

    Ultra-long Endurance

    Automatic Battery Swap

    AR Fusion Technology

    TapFly

    Automatic Route Creation

    Obstacle Avoidance

    Completely Remote Operation

    Multi-terminal Synchronization

    Cloud Platform:


    GODO A170 Automatic Drone Dock System | Drone-in-a-Box

    FAQ:


    Q1:What is the minimum quantity I need to order?

    A:At least 1 unit needs to be ordered.

    Q2:How long is the delivery time?

    A:Mass production takes 40 working days.

    Q3:What is the shipping method?

    A:Because our products are heavy equipment, we have chosen sea transportation.

    Q4:What is the process of processing orders?

    A:Firstly, we will form a preliminary order based on your request or our suggested quotation plan,after you confirm the accuracy of the details, we will proceed with the formal order and finally start arranging production.

    Q5:Can I print my logo on the product?

    A:Yes. Please inform us formally before production.

    Q6:Can I get a discount?

    A:Please contact our sales manager.


    TAG:GODO UAV intelligent dock,Automatic battery replacement dock,UAV fully automatic dock,UAV intelligent dock,Unattended drone,Fully automatic aerial photography drone,Remote dispatching patrol drone,Fully automatic inspection drone,Fully automatic patrol drone,Ultra Long endurance drone,Pure electric drone,UAV inspection system,Power facilities inspection,Water patrol,Security Patrol,Public Security Patrol,Maritime patrol,Energy facility inspection,Environmental Patrol,Forest patrol,Emergency rescue patrol
